Siemens SIMATIC HMI KTP400 Basic mono Description:
Cost-effective device with a very small footprint for small-scale HMI tasks for PROFINET connection
Area of application:
Panel for HMI tasks of limited complexity; for the use in PROFINET networks; particularly suitable for cramped space conditions directly at the machine especially in combination with SIMATIC S7-1200 controllers but also with other controllers.
Benefits:
1.HMI basic functionality
2.Lowest priced Basic Panel with touch functionality
3.Compact, space-saving design
4.Can be used worldwide with 32 configurable languages
(of which 5 are online-switchable)
The KTP400 Basic mono is equipped with a 3.8 inch STN- display offering 4 grey scales. A resolution of 320 x 240 pixels enables the representation of less complex operating screens. The panel can be operated by a resistive analog touch screen and additionally by 4 freely configurable function keys which – when actuated – provide tactile feedback.
The KTP400 Basic mono is the ideal HMI-component for the small S7-1200 controller systems.
It can be configured by using WinCC flexible Compact or WinCC Basic (TIA Portal). The KTP400 offers HMI basic functionality (alarms, trend curves, recipes) with 250 tags.
Contact us any time.
